3D Polarizer Modulator Vertical Triple Beam Polarization digital 3D Cinema System CH600

FOB Reference Price:Get Latest Price
1 Set/Sets (Min. Order)
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Model Number:
Play house
Operating Voltage:
110V-240V AC
Operating Current:
Operating Temperature:
Above 70%
Optical Efficiency:
Above 28%
Polarized Light Input:
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
customized packing

3D Polarizer Modulator Vertical Triple Beam Polarization digital 3D Cinema System CH600



1,3D-HCBL-CH600 electrical parameters & Optical parameter:

Operating voltage110V-240V AC
Operating current4A
Operating temperature0℃~60℃
Operating humidity 20%-90%RH
Transmittance Above 70%
Optical efficiencyAbove 28%
Polarized light input (light valve) transmittance86%-90%
Degree of polarizationAbove 99.999%
Contrast ratio80:1
Support frame frequency96Hz-480Hz
Operating temperature-10℃~60℃
Ghost rateBelow 2%
Polarization typeCircular polarization RD model


2,  Description:

1 ,  Assembly units:

1 3D-HCBL-CH600 system components (main case, server)

2 3D-HCBL-CH600 stands

3 Accessories, synchronous signal cables


2,  Attentions before installation:

To understand the actual situation of installation site

1 The show window size should not less than 600*600mm

2 The distance from projector lens to the projection window not less than 300mm

3 Lens zoom ratio range is greater than 1.2:1

4 The lens center with top of projection window should more than 250 mm


Related information:

 we have a garantee of 3 years
